Chainring Carbon Ti X-CarboRing EVO 52 x 110 (4 Arms)

Carbon Ti X-CarboRing EVO 52T 110 BCD (4 Arms) Chainring

The Carbon Ti X-CarboRing EVO 52 x 110 (4 Arms) is a super lightweight outer chainring for road bikes, designed for demanding cyclists seeking maximum stiffness, shifting precision, and racing performance.
It is part of the X-CarboRing EVO line, the most advanced evolution of Carbon-Ti chainrings with a composite structure of aluminum and carbon fiber.

EVO technology: superior stiffness and lightning-fast shifting

The term EVO identifies the new generation outer chainrings that adopt the innovations introduced with the X-AXS chainrings, optimized for Shimano and SRAM 11-speed groups.

In particular:

• the outer chainrings are made from carbon fiber plates with increased thickness

• the increased stiffness allows for more complex and precise CNC machining

• the advanced climbing ramps, combined with the redesigned Grade 5 Titanium pins, “hook” the chain and facilitate its transition from the inner to the outer chainring

The result is extremely fast and reliable shifting, both with electronic derailleurs and mechanical ones.

Premium materials and construction

The X-CarboRing EVO combines top-level materials:

• AL7075-T6 aluminum alloy teeth, individually CNC machined

• Structural carbon fiber with glossy 3K finish

• Grade 5 Titanium shift pins

This structure guarantees an excellent stiffness/weight ratio and consistent performance even under high loads.

Compatibility

• Number of teeth: 52 (outer multiplier)

• Bolt circle (BCD): 110 mm

• Interface: 4 Arms

• Compatible with cranksets:

  • PowerMeter SRM Origin

  • Rotor INSpider

• Group compatibility:

  • Shimano 12 speed

  • Shimano 11 speed

  • SRAM 11 speed

• Not compatible with:

  • SRAM AXS 12 speed (for these groupsets choose the specific X-AXS chainrings)

• Requires installation paired with:

  • Inner chainring X-CarboRing 36 x 110 (4 Arms)

Recommended installation

For installation, the use of the X-Fix ROAD screw kit is recommended, made of AL7075-T6 alloy, customized with laser engravings and available in a wide range of anodized colors.

Available size range

The X-CarboRing EVO are available in the following combinations:

• 53/39

• 52/36

• 50/34

• 54/40

Compatibility is guaranteed with Shimano 11 and 12 speed chains and groupsets and SRAM 11 speed.

Technical specifications

• Model: X-CarboRing EVO

• Type: Outer chainring

• Teeth: 52

• BCD: 110 mm

• Arms: 4

• Teeth material: CNC machined AL7075-T6 Aluminum

• Structure: Structural carbon fiber

• Finish: Glossy 3K Carbon

• Shift pins: Grade 5 Titanium

• Transmission compatibility: Shimano 11v / 12v, SRAM 11v

• Production: 100% Made in Italy

Like all Carbon-Ti products, the X-CarboRing EVO are also entirely designed and manufactured in Italy, a synonym of artisan quality, innovation, and uncompromising performance.
