SpeedFun Furious Evo easy+ for Bosch Performance Line SX (gen. 4) Smart System – Rim Magnet for BDU3143 Motor

CHF 183.00
by SpeedFun
Type: spare-parts-for-bikes-and-e-bikes
SKU: FuriousEvoBoschRimMagnetSXBDU3143
Discover more about the product

SpeedFun Furious Evo easy+ is a tuning for ebikes equipped with Bosch Smart System motor that allows removing the 25 km/h speed limit.

This unlocking device is compatible only and exclusively with Bosch Performance Line SX (gen 4) motors equipped with a magnet on the valve (Bosch Rim Magnet) regardless of the display or handlebar control.

All SpeedFun Furious Evo speed unlocking devices can be activated and deactivated at any time without the need for connections to the light output.


BEFORE PURCHASING THIS DEVICE, IT IS NECESSARY TO CHECK THE “PRODUCT CODE” OF YOUR BOSCH PERFORMANCE LINE SX MOTOR.

THE “PRODUCT CODE” IS PRINTED ON THE MOTOR LABEL.



What is the SpeedFun Furious Evo tuning for Bosch Performance Line SX (gen. 4) Smart System – Rim Magnet?

The function of the Furious Evo tuning device for Bosch Smart System is to electronically manipulate the rear wheel rotation speed and communicate to the motor a speed always below 25 KmH in order to achieve a very high real speed with the motor active. The maximum speed limit will therefore be dictated by the motor power added to the power expressed by your own legs.

When the device is active, the display will show the exact speed up to a threshold of about 20 KmH, beyond which a manipulated speed always below 25 KmH will be shown.

This speed unlocking device is compatible only and exclusively with Bosch Performance Line SX (gen.4) motors equipped with a magnet on the valve (Bosch Rim Magnet) with LED Remote/System Controller command (also compatible with Led Remote + Kiox 300/500, Intuvia 100, Purion 400 or System Controller + Mini Remote) or Purion 200.

SpeedFun Furious Evo comes ready to use, plug and go, can be activated and deactivated at will, and retains the setting even after the ebike is turned off. It can be easily installed thanks to compatible connectors.

The kit includes all the necessary elements for installation, ensuring extremely easy assembly.

All these components have been specially designed and manufactured by us to ensure correct placement of the parts during installation and to avoid malfunctions over time or issues during your rides.

Since these parts are made internally by our company, they have been specifically designed to best fit the Bosch Performance Line SX (gen. 4) Smart System motor.

WARNING!
This device is not compatible with ebikes equipped with a “classic” magnet on the spokes or brake disc.
This device is not compatible with ebikes equipped with Bosch ABS system.
This device is not compatible with ebikes equipped with GPS system (Bosch ConnectModule).



Ebike with Bosch Performance Line SX Smart System motor (gen. 4) – Rim Magnet where the Furious Evo easy+ device has been successfully installed

(this list is exemplary and not exhaustive)



– Focus JAM² 6.9
– Focus JAM² 6.7
– Focus JAM² 6.0

– Santa Cruz Vala XX AXS RSV
– Santa Cruz Vala X0 AXS RSV
– Santa Cruz Vala S
– Santa Cruz Vala R
– Santa Cruz Vala GX AXS

– Trek Rail+ 9.9/Rail+ 9.8/Rail+ 9.7/Rail+ 8/Rail+ 5 Gen 5 (2025)
– Trek Powerfly+ 8/Powerfly+ 6/Powerfly+ 4 Gen 5 (2025)



Additional information

  • Installation: Internal (completely invisible from the outside)
  • Dimensions: 37 x 22 x 7.5 mm
  • Connections: Equipped with original and/or compatible connectors (no physical modification to the ebike wiring required)
  • Assistance: Over 60 km/h
  • Compatible motors: Bosch Performance Line SX gen4 (BDU3143)
  • Compatible sensor type: Wireless Rim Magnet sensor (magnet on the valve)
  • Compatible displays: Bosch LED Remote, Bosch System Controller, Intuvia 100, Kiox 300, Kiox 500, Mini Remote, Purion 200, Purion 400
  • Displayed data (on display or app): Altered (variables above a certain threshold)
  • Power supply: No external power supply needed



WARNINGONE - IMPORTANT NOTICE

Once the SpeedFun speed unlocking device is installed, the electric bicycle, exceeding the 25 km/h limit, is classified as a moped and as such, if used in public places, requires approval-registration by the Motor Vehicle Department, is subject to road tax and insurance coverage, must have a license plate, cannot be ridden on bike paths, and the rider is required to have a license and wear a helmet. Furthermore, riding a motor-assisted bicycle classified as a moped without observing these provisions results in administrative seizure of the vehicle and fines that vary depending on the violation committed. The manufacturer of the speed unlocking system declines all responsibility for any damage caused to pedal-assist bicycles on which the device is installed, as well as for direct or indirect damage to people or property.
SpeedFun – Phase B snc declines all responsibility for any malfunctions caused by anti-tuning protections that motor manufacturers may activate.
Please note that modifying the bicycle may void the manufacturer's warranty.



SOFTWARE COMPATIBLE WITH SPEEDFUN DEVICES

The operation of SpeedFun devices is guaranteed for ebike software versions released up to the date of purchase of the device itself.
If the ebike is later updated with software for which the SpeedFun device was not designed, it may stop working.
Before upgrading your motor, it is necessary to check compatibility with your SpeedFun device.
